Shelf rack – add-on module M21

W skład zestawu modułu dostawnego M21 wchodzi:

• 1 rama kompletna 2000 mm ocynkowana
• 4 półki ocynkowane
• 1 leveling washer 1 mm galvanized
• 1 leveling washer 3 mm galvanized
• Naklejki z nośnością 160 kg / 4 szt.
• Instruction

Note: A shelf brace must be installed for every four shelf modules.

We issue a declaration of conformity necessary for the storage of goods, which is required by the National Labor Inspectorate.

Mshelf shelf rack can be used anywhere from an office to an industrial warehouse. Shelf load capacity Depending on the dimension, it can be up to 200 kg. Thanks to the frame that can be moved load up to 4000 kg it is possible to create a multi-story rack structure – mezzanine.

Supporting frame – composed of two legs (posts), diagonal beams and feet ensuring excellent stiffness buckling and bending-torsion.

Shelf – four-fold bent (there is no possibility of injury), galvanized, is mounted on special snap hooks, shelf height 35 mm.

Feet – galvanized, each time converted into loads transferred from the column to the floor for even distribution of loads. It is possible to attach each foot to the floor using a very durable anchor.

Perforation - allows you to free adjustment of shelf levels to suit your needs. The perforation is made exclusively on CNC machines with very small manufacturing tolerances, giving the structure extraordinary rigidity.

Still to be assured better stability and durability we use the shelf cross concentration.

All our shelves are subjected to special tests and static calculations carried out in accordance with strict and rigorous standards EN.EU-15.512 and FEM 10.3.01 standards.

Check out the other metal shelves with shelves in our offer.

*The operating and assembly manual is available for download in the "my account" tab after purchasing the product
